Powertrain & Battery Scissor Lifter
- Product Code: P07-0220
- Brand: TQ Pro
The TQ Pro Air/Hydraulic Powertrain & Battery Lifter is a heavy-duty solution specifically engineered for the safe removal and installation of large electric vehicle batteries and complex powertrain assemblies. Built for professional workshop environments, this lifter features a robust air-actuated hydraulic system that provides a smooth, controlled lift, while maintaining a substantial safe working capacity for heavy components. The versatile lifting platform is extendable in length and offers a fore/aft tilt adjustment, ensuring precise alignment with vehicle mounting points during critical maneuvers. Designed for effortless maneuverability, it is equipped with high-grade swivel castors and a long-reach handle, making it an essential tool for technicians working on modern EV and hybrid drivetrain systems.
Features
- Equipped with heavy-duty 8" caster wheels
- 1,100kg safe working capacity
- Extendable platform
- 2° front & rear tilt adjustable
- Heavy-duty 8" caster wheels
- Includes rubber head accessory kit
- Integrated Auto Safety Lock function
- Maximum height of 2,141 mm (with accessory kit)
Specifications
- Safe working capacity: 1,100kg
- Air/Hydraulic pump: 5800psi
- Control cable length: 2438mm
- Lift table size: 762 mm x 1,524 mm
- Lift table extended size: 762 mm x 1,828 mm
- Overall length: 1,682.7 mm
- Overall width: 774.7 mm
- Lift table Front/Rear tilt: 2 degrees
- Lift table hole size: 3/8-16 unc
- Low height: 586.74mm
- Max lifting height with accessory kit: 2141.22 mm
- Caster wheel diameter: 203.2 mm
- Handle length: 863.6 mm
- Net Weight: 377kg
- Gross Weight: 455kg
Intended Use
For lifting both heavy and light work pieces and workloads. Scissor Lift tables raise, position, and transport workloads and workpieces to minimise risk of injury.
